AlleRad ExPACS™ Picture Archiving & Communication System

Scalable, Standards‑Based Image Archiving for Hospitals, Imaging Centers & Teleradiology Networks

AlleRad ExPACS™ is Pixel Technology’s flagship PACS platform. Built around full DICOM 3.0 conformance, it consolidates every imaging study produced across your enterprise into a single, high‑availability archive, then streams those studies instantly to clinicians—without the bottlenecks of film, portable media or workstation‑to‑workstation transfers.

Key Features

Centralised DICOM 3.0 Archive: One server stores, indexes and protects all CT, MR, US, CR/DR, NM, XA and secondary‑capture objects—with lossless compression options for long‑term retention.
Elastic Licensing Model: Select the capacity you need today (from a few terabytes to multi‑petabyte clusters) and expand later by licence—hardware and software grow with your imaging volume.
Multi‑Site Image Distribution: A built‑in Image Distribution Server pushes studies and reports to every ward, clinic or satellite site; physicians view exams in the bundled Exhibeon DICOM viewer without waiting for file transfers.
Modality & HIS/RIS Worklist Integration: HL7 and DICOM MWL / MPPS streamline scheduling, eliminate duplicate data entry and feed results back to the EHR automatically.
Online + Nearline + Offline Storage: Tiered disk‑and‑nearline architecture, plus SmartOn™ offline archiving, balance instant availability with economical, long‑life media.
DICOM Video & Cine Support: Stores and streams ultrasound loops and XA runs with the same ease as static images.
Patient CD/DVD Generation: One‑click disc burning with viewer autorun simplifies external referrals and medico‑legal requests.
System Workload Analytics: Built‑in dashboards track modality queues, report turnaround and archive growth for continuous quality improvement.
Web‑Enabled, Zero‑Footprint Viewer Option: Clinicians can launch a diagnostic‑grade viewer directly from the HIS portal—no local install required.

Technical Specifications

Standards	Full DICOM 3.0, HL7 v2.x, IHE‑PDI, IHE‑XDS‑I compliant
Supported OS	Windows Server 2008 R2 / 2012 R2 (32/64‑bit) · Linux (32/64‑bit)
Archive Scalability	Licence‑based tiers from < 1 TB to multi‑PB; online, nearline and offline tiers configurable
Concurrent Devices	Unlimited—number of connected modalities and workstations determined only by purchased licence
Throughput	Optimised for multislice CT rates ≥ 800 images min⁻¹; supports parallel DICOM C‑STORE and WADO‑RS sessions
Security	Role‑based access, AES‑256 encrypted storage option, LDAP / AD authentication, full audit trail
Disaster Recovery	Hot replication, snapshot backup, and PACS‑to‑PACS mirroring across data‑centres

Why Choose AlleRad ExPACS™?

: Future‑Proof Standards – certified DICOM 3.0 and HL7 conformance keep your archive interoperable with any modality or HIS/RIS you add tomorrow.
: License‑Right, Scale‑Easy Economics – pay only for the capacity and device seats you need; expand with a licence key instead of forklift upgrades.
: Zero‑Delay Image Access – studies are available to clinicians the moment they hit the archive—no manual export or physical media.
: Comprehensive Video Handling – natively archives ultrasound, endoscopy and angiography loops so there’s no “special case” workflow.
: Integrated Distribution & Viewer – bundled Exhibeon viewer and ward‑friendly distribution server put diagnostic images and final reports in every department.
: Proven in Demanding Environments – relies on the same Pixel Technology codebase trusted by more than 200 hospitals and imaging centres across Europe.

AlleRad ExPACS™ delivers the robust storage, lightning‑fast distribution and flexible growth path modern radiology demands—helping your team eliminate silos, accelerate diagnosis and safeguard every imaging study for decades to come.
