DGH Scanmate Flex A/B/UBM

DGH Scanmate Flex A/B/UBM
DGH Scanmate Flex A/B/UBM

Ultra‑Portable Ultrasound Biomicroscope for High‑Resolution Anterior‑Segment Imaging

The Scanmate Flex™ UBM probe transforms any Windows® workstation into a powerful ultrasound biomicroscope, capturing crystal‑clear cross‑sections of the anterior segment—even when pathology or opacities block optical techniques. Its dual‑frequency design, water‑path ClearScan® probe cover, and battery‑powered base unit give clinicians a fast, accurate, and truly mobile solution for angle analysis, sulcus‑to‑sulcus measurements, ICL planning, and post‑operative evaluations.

Key Features
  • High‑Resolution Dual‑Frequency Imaging: 35 MHz and 50 MHz transducer options tailor depth and resolution to each case. 30° sector scan with 256 lines delivers detailed, artifact‑free views of the cornea, anterior chamber, iris, and ciliary body.
  • Water‑Path ClearScan® Probe Cover: Single‑use, sterile cover creates a smooth water interface—no messy immersion shells—while ensuring patient comfort and infection control.
  • Comprehensive Measurement Toolkit: On‑screen calipers for distance, angle, and area plus free‑text annotations help document pathologies and support surgical planning.
  • True Grab‑and‑Go Portability: Compact base (209 × 134 × 102 mm, 8 lb) houses an internal 3250 mAh Li‑ion battery for untethered use on a desk, wall mount, or rolling cart. Probe and tablet fit into the supplied carrying case for easy transport between sites.
  • Unlimited Software Licensing & EMR Connectivity: Install the Scanmate software on multiple PCs at no extra cost; local or network databases back up and share studies seamlessly. Export images and reports as PDF or JPG for effortless charting and referrals.
  • Typical Diagnostic Applications: Angle‑closure assessment and ACA measurement. Sulcus‑to‑sulcus sizing for phakic IOL selection. IOL position monitoring and post‑LASIK corneal evaluation. Iris and ciliary‑body cysts or tumors. Glaucoma post‑surgery follow‑up.
Why Choose Scanmate Flex™ UBM?
  • : Superior image quality with selectable high‑ and ultra‑high‑frequency modes.
  • : Water‑path ClearScan® cover delivers sterile, contact‑free coupling in seconds.
  • : Battery‑powered portability lets you image anywhere—clinic chair, OR, or outreach site.
  • : Rich measurement tools and unlimited software seats streamline workflow and support collaborative care.
  • : Scalable platform—add A‑Scan or B‑Scan probes later to create a full ultrasound suite without extra hardware.

Scanmate Flex™ UBM puts high‑definition anterior‑segment imaging in the palm of your hand—empowering clinicians to diagnose, plan, and monitor with confidence wherever care takes them.
